EnzymeLogic.h File Reference

#include <algorithm>
#include <set>
#include <utility>
#include "llvm/IR/Function.h"
#include "llvm/IR/Module.h"
#include "llvm/IR/Type.h"
#include "llvm/Support/CommandLine.h"
#include "llvm/Analysis/AliasAnalysis.h"
#include "llvm/ADT/SmallVector.h"
#include "llvm/Support/ErrorHandling.h"
#include "ActivityAnalysis.h"
#include "FunctionUtils.h"
#include "TraceUtils.h"
#include "TypeAnalysis/TypeAnalysis.h"
#include "Utils.h"
#include "mlir/IR/IRMapping.h"
#include "mlir/Interfaces/FunctionInterfaces.h"
#include "../../Utils.h"
#include <functional>

Include dependency graph for EnzymeLogic.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	AugmentedReturn
	return structtype if recursive function More...
struct	ReverseCacheKey
	todiff is the function to differentiate retType is the activity info of the return. More...
struct	RequestContext
struct	FloatRepresentation
struct	FloatTruncation
class	EnzymeLogic
struct	EnzymeLogic::AugmentedCacheKey
struct	EnzymeLogic::ForwardCacheKey
class	mlir::enzyme::MFnTypeInfo
class	mlir::enzyme::MTypeAnalysis
class	mlir::enzyme::MTypeResults
class	mlir::enzyme::MEnzymeLogic
struct	mlir::enzyme::MEnzymeLogic::MForwardCacheKey
struct	mlir::enzyme::MEnzymeLogic::MReverseCacheKey

Namespaces
namespace	mlir
namespace	mlir::enzyme

Typedefs
typedef void	mlir::enzyme::buildReturnFunction(OpBuilder &, mlir::Block *)

Enumerations
enum class	AugmentedStruct { Tape , Return , DifferentialReturn }
enum class	CacheType { Self , Shadow , Tape }
enum	TruncateMode { TruncMemMode = 0b0001 , TruncOpMode = 0b0010 , TruncOpFullModuleMode = 0b0110 }

Functions
static std::string	str (AugmentedStruct c)
static llvm::raw_ostream &	operator<< (llvm::raw_ostream &o, AugmentedStruct c)
static std::string	str (CacheType c)
static llvm::raw_ostream &	operator<< (llvm::raw_ostream &o, CacheType c)
static llvm::Type *	getTypeForWidth (llvm::LLVMContext &ctx, unsigned width, bool builtinFloat)
static const char *	truncateModeStr (TruncateMode mode)
bool	shouldAugmentCall (llvm::CallInst *op, const GradientUtils *gutils)
bool	legalCombinedForwardReverse (llvm::CallInst *origop, const std::map< llvm::ReturnInst *, llvm::StoreInst * > &replacedReturns, llvm::SmallVectorImpl< llvm::Instruction * > &postCreate, llvm::SmallVectorImpl< llvm::Instruction * > &userReplace, const GradientUtils *gutils, const llvm::SmallPtrSetImpl< const llvm::Instruction * > &unnecessaryInstructions, const llvm::SmallPtrSetImpl< llvm::BasicBlock * > &oldUnreachable, const bool subretused)
std::pair< llvm::SmallVector< llvm::Type *, 4 >, llvm::SmallVector< llvm::Type *, 4 > >	getDefaultFunctionTypeForAugmentation (llvm::FunctionType *called, bool returnUsed, DIFFE_TYPE retType)
std::pair< llvm::SmallVector< llvm::Type *, 4 >, llvm::SmallVector< llvm::Type *, 4 > >	getDefaultFunctionTypeForGradient (llvm::FunctionType *called, DIFFE_TYPE retType)

Variables
llvm::cl::opt< bool >	EnzymePrint
constexpr char	EnzymeFPRTPrefix [] = "__enzyme_fprt_"
constexpr char	EnzymeFPRTOriginalPrefix [] = "__enzyme_fprt_original_"
llvm::cl::opt< bool >	looseTypeAnalysis
llvm::cl::opt< bool >	nonmarkedglobals_inactiveloads

Enumeration Type Documentation

AugmentedStruct

enum class AugmentedStruct

strong

Enumerator
Tape
Return
DifferentialReturn

Definition at line 60 of file EnzymeLogic.h.

CacheType

enum class CacheType

strong

Enumerator
Self
Shadow
Tape

Definition at line 80 of file EnzymeLogic.h.

TruncateMode

enum TruncateMode

Enumerator
TruncMemMode
TruncOpMode
TruncOpFullModuleMode

Definition at line 336 of file EnzymeLogic.h.

Function Documentation

getDefaultFunctionTypeForAugmentation()

std::pair< llvm::SmallVector< llvm::Type *, 4 >, llvm::SmallVector< llvm::Type *, 4 > > getDefaultFunctionTypeForAugmentation	(	llvm::FunctionType *	called,
		bool	returnUsed,
		DIFFE_TYPE	retType )

getDefaultFunctionTypeForGradient()

std::pair< llvm::SmallVector< llvm::Type *, 4 >, llvm::SmallVector< llvm::Type *, 4 > > getDefaultFunctionTypeForGradient	(	llvm::FunctionType *	called,
		DIFFE_TYPE	retType )

getTypeForWidth()

static llvm::Type * getTypeForWidth ( llvm::LLVMContext & ctx, unsigned width, bool builtinFloat )

static

Definition at line 319 of file EnzymeLogic.h.

legalCombinedForwardReverse()

bool legalCombinedForwardReverse	(	llvm::CallInst *	origop,
		const std::map< llvm::ReturnInst *, llvm::StoreInst * > &	replacedReturns,
		llvm::SmallVectorImpl< llvm::Instruction * > &	postCreate,
		llvm::SmallVectorImpl< llvm::Instruction * > &	userReplace,
		const GradientUtils *	gutils,
		const llvm::SmallPtrSetImpl< const llvm::Instruction * > &	unnecessaryInstructions,
		const llvm::SmallPtrSetImpl< llvm::BasicBlock * > &	oldUnreachable,
		const bool	subretused )

operator<<() [1/2]

static llvm::raw_ostream & operator<< ( llvm::raw_ostream & o, AugmentedStruct c )

inlinestatic

Definition at line 75 of file EnzymeLogic.h.

operator<<() [2/2]

static llvm::raw_ostream & operator<< ( llvm::raw_ostream & o, CacheType c )

inlinestatic

Definition at line 95 of file EnzymeLogic.h.

shouldAugmentCall()

bool shouldAugmentCall	(	llvm::CallInst *	op,
		const GradientUtils *	gutils )

str() [1/2]

static std::string str ( AugmentedStruct c )

inlinestatic

Definition at line 62 of file EnzymeLogic.h.

Referenced by convertRRootCountFromString(), convertSRetTypeFromString(), dontAnalyze(), EmitFailure(), EmitFailure(), EmitFailure(), EmitNoDerivativeError(), EmitNoDerivativeError(), EmitNoTypeError(), EmitWarning(), EmitWarning(), EmitWarningAlways(), EnzymeAnonymousAliasScope(), EnzymeAnonymousAliasScopeDomain(), EnzymeGradientUtilsInvertedPointersToString(), EnzymeTypeAnalyzerToString(), CacheUtility::erase(), ErrorIfRuntimeInactive(), extractBLAS(), TypeResults::firstPointer(), getOrInsertDifferentialMPI_Wait(), handleCustomDerivative(), isMemFreeLibMFunction(), parseActivityString(), parseBaseType(), AdjointGenerator::recursivelyHandleSubfunction(), SanitizeDerivatives(), TypeAnalyzer::visitBinaryOperation(), AdjointGenerator::visitCastInst(), AdjointGenerator::visitCommonStore(), AdjointGenerator::visitExtractValueInst(), AdjointGenerator::visitInsertValueInst(), TypeAnalyzer::visitIntrinsicInst(), AdjointGenerator::visitLoadLike(), AdjointGenerator::visitMemSetCommon(), AdjointGenerator::visitMemTransferCommon(), TypeAnalyzer::visitMemTransferCommon(), and TypeAnalyzer::visitPHINode().

str() [2/2]

static std::string str ( CacheType c )

inlinestatic

Definition at line 82 of file EnzymeLogic.h.

truncateModeStr()

static const char * truncateModeStr ( TruncateMode mode )

static

Definition at line 341 of file EnzymeLogic.h.

Variable Documentation

EnzymeFPRTOriginalPrefix

char EnzymeFPRTOriginalPrefix[] = "__enzyme_fprt_original_"

constexpr

Definition at line 58 of file EnzymeLogic.h.

EnzymeFPRTPrefix

char EnzymeFPRTPrefix[] = "__enzyme_fprt_"

constexpr

Definition at line 57 of file EnzymeLogic.h.

EnzymePrint

llvm::cl::opt<bool> EnzymePrint

extern

Referenced by PreProcessCache::preprocessForClone().

looseTypeAnalysis

llvm::cl::opt<bool> looseTypeAnalysis

extern

Referenced by AdjointGenerator::createBinaryOperatorAdjoint(), AdjointGenerator::createBinaryOperatorDual(), AdjointGenerator::createSelectInstAdjoint(), AdjointGenerator::DifferentiableMemCopyFloats(), AdjointGenerator::handleAdjointForIntrinsic(), AdjointGenerator::visitAtomicRMWInst(), AdjointGenerator::visitCastInst(), AdjointGenerator::visitCommonStore(), AdjointGenerator::visitExtractValueInst(), AdjointGenerator::visitInsertValueInst(), AdjointGenerator::visitLoadLike(), AdjointGenerator::visitMemSetCommon(), and AdjointGenerator::visitMemTransferCommon().

nonmarkedglobals_inactiveloads

llvm::cl::opt<bool> nonmarkedglobals_inactiveloads

extern

Referenced by AdjointGenerator::visitLoadLike().
